| Product name | PP/PE Tube |
| Material | Polypropylene and Polyethylene |
| Size | OD: 0.3mm-15.0mm; ID: 0.2mm-14.5mm. |
| Tolerance | ±0.05mm-±0.15mm |
| Color | Nature/Customized |
| Develop condition | Milk white/Translucent; 20-40% BaSO4. |
| MOQ | 2000 meters |
| Package | PE bags into carton |
| Payment term | 100% T/T advance payment; or L/C at sight. |
| Delivery time | 15~25 days after order confirmed. |
| Properties of PP | Polypropylene is of low density and good electric property and high frequency insulation, and its intensity, rigidity, hardness and resistance to heat are all better than low pressure polyethylene. |
| Properties of PE | Polyethylene is known for its good corrosion resistance, fatigue resistance and wearproof, impact strength and permeability. It has excellent chemical resistant property and lower coefficient, which makes it move smoothly and easy to handle. |
| Other | Tip forming, punching and printing as requirement. |
Material Characteristic:
| HDPE | LDPE | PA12 | PEBAX | TPU | PP | |
| Density | 0.96 | 0.93 | 1.15 | 1.01 | 1.2-1.25 | 0.88 |
| Rigidity | 60D-65D | 48D-53D | 68D-70D | 23D-72D | 60A-75D | 60-69D |
| Max. Operation temperature | 54ºC | 54ºC | 80ºC | 80ºC | 80~100ºC | 80~100ºC |
| Min. Operation temperature | -40ºC | -40ºC | -40ºC | -20ºC | -35ºC | -20ºC |
| Tenacity | Commonly | good | commonly | commonly | Excellent | commonly |
| Color | Milk White | Translucent | Translucent | Transparent | Transparent | Translucent |
| Reprocessing performance Characteristics | Commonly | Easy | Easy | Easy | Easy | Commonly |
| Chemical Resistance | Good | Good | Good | Good | Commonly | Good |
| Insulation | Good | Good | Good | Good | Good | Good |
| Biocompatibility | Good | Good | Excellent | Excellent | Excellent | Good |
| Medical Grade Attestation | Yes | yes | yes | yes | yes | yes |
Our Company:
Kunshan Bova Plastic Co., Ltd.Was established in 2008, now located at NO.578 Jujin Road, Zhangpu Town, Kunshan City, Jiangsu Province.The company mainly provides precision extrusion catheter, secondary operation for catheter and catheter custom-made service.The company produces various materials such as TPU,PE,PP,PVC,Pebax,PA,PEEK,PSU,PPSU,PC,EVA,TPE,ABS,PCL,PLA,PTFE,FEP,Silica and various shapes of extruded pipes, such as single-lumen tubes, multi-row tubes, multi-color co-extrusion tubes, multi-layer coated tubes, X-ray development tubes, Thin-walled tube, metal-coated plastic tube, microcatheter, etc., The company has been committed to the production of plastic precision extrusion and catheter product research and development since its establishment.At present, the diameter deviation of extruded pipe can be controlled at ±0.02 mm, and the wall thickness can reach 0.06 mm.The company owns standard 100000 level clean room for production and passed ISO9001 quality system certification in 2016 and ISO13485 quality system certification in 2019.
Major Products:
Medical Grade PA/PEBAX tube, HDPE tube, LDPE tube, PU/TPU/TPE tube, PVC tube, PP/PE tube, PC tube, PS tube, ABS tube, etc.
Delivery:
For product in stock, we will ship within 3-5 days.
For OEM product, please inquire.
Transport Package:Double layer PE bags→Carton→Pallet
Payment Item:T/T ,50% Deposit, 50% Balance Before Shipment.
FAQ:
Example of the problem we can solve
| Q Are you trading company or factory? |
| Q Can you manufacture the product without any burr? |
| Q Can you manufacture the colored tube in small quantities?There are no company accepting such product order. |
| Q Can you deal with the product whose thickness is so thin that it is difficult to manufacture? |
| Q Can you Manufacture the product in the company which is authorized by ISO 13485 and has the clean-room facility? |
| Q Can you provide free sample? |
ORDER FLOW:
CONTACT
Please let us know the specifications of the desired component via e-mail or Mobile phone.
Verify prototype specifications
We will confirm whether or not it is possible to produce according to specifications, and make suggestions if changes are necessary.
Decide prototype specifications
We will decide on the specifications after reaching an understanding(shape-quote,etc.)
Receive orders
Take orders according to the specifications which are decided upon.
Produce prototypes
Produce prototypes using materials and manufacturing method according to specifications.
Verify prototype
Double check finished products within the company for products manufactured at cooperative companies.
Distribution
Delivery products with specifications as agreed upon in the quote.
Need more information, contact Us Freely
